履带尺寸Track size |
2800*2200mm |
|
装车尺寸Loading size |
3500*2200*3200mm |
|
履带板宽Track shoe width |
400mm |
|
钻孔直径Borehole diameter |
50-400mm |
|
钻孔深度Drilling depth |
一杆3m |
|
钻杆转速Drill pipe speed |
90r/min |
|
爬坡度Gradient |
30° |
|
动力头Power head |
22kw |
|
油泵电机Oil pump motor |
15kw |
|
油泵Oil pump |
两联Two couplets |
|
油泵型号Oil pump model |
CBG1-F040/040 |
|
油泵转速Oil pump speed |
2000-2400L/min |
|
油泵压力Oil pump pressure |
30Mpa |
|
油泵扭矩Oil pump torque |
3000N |
|
发电机组Generator Set |
50kw（特斯拉） |
|
操作方式Operation mode |
液压hydraulic pressure |
|
液压油散热器Hydraulic oil radiator |
强风a fierce wind |
|
燃油箱、液压油箱Fuel tank, hydraulic tank |
各一个One each |
|
整车重量Vehicle weight |
6T |
|
桅杆mast |
左右、上下可调Left and right, up and down adjustable |
